Attenta alle esigenze del mercato ed alla domanda di soluzioni pronte all'uso, EDT ha realizzato la sua serie di display Smart Embedded®.
Sulla base comune del processore ARM Cortex M7 STM32F746 sono stati costruiti tre modelli con i display EDT di maggior successo: 4.3", 7.0" e 10.1".
Con questa innovativa proposta EDT si offre di rilevare tutto il carico di lavoro del cliente rendendo la realizzazione delle GUI più semplice, più veloce, più flessibile e più vantaggiosa. Gli Smart Embedded® display di EDT consentono di creare GUI moderne, con grafica di alta qualità ed animazioni fluide senza sovraccaricare il sistema operativo in termini di consumi e memoria.
Smart Embedded by EDT means a total integration of Display/Touch/Cover Lens/Embedded board/Software GUI, that provides fast proof of concept, rapid development and warranty from just one supplier - shorter time to market! Less transportation, less stocking and test of sub-assemblies, reducing cost and energy consumption. High product quality level to reduce material waste. Long availability and a strong partnership.
What is our Smart Embedded Solution?Why should you choose the Smart Embedded solution?What are the benefits of cooperating with EDT?
Well it is a total integration of Display/Touch/Cover lens/Embedded board/Software GUI. The SE solution provides fast proof of concept, rapid development and full warranty from a qualified and reliable supplier and that means shorter time to market! More than 25 years of experience within developing and manufacturing Display & Touch integrated modules, with the focus on...
As a member of the ST Partner Program, we have produced a module that bundles STM32F7 respectively STM32H7 MCU board, an industrial TFT display with a capacitive touch panel sensor as well as a cover lens, and a number of industrial interfaces, to offer a one-stop solution when designing an embedded system with a display. When going deeper into technical details you see that the following Interfaces, RS232, RS485, CAN, I2C, SPI, USB-OTG, GPIO are available on the Smart Embedded module and some modules also include Ethernet/PoE. The Industrial interfaces enables you to control your new or existing system and the I2C/SPI can connect to all kind of Sensors, BLE, Wi Fi, LoRa modules etc. Having aHaving a wide power supply input range of 7 to 36 Volt - makes it easier to integrate the module to general power supply unit, if it is used in a 'mockup' of a prototype for a new product. The USB-OTG can be used for different USB classes. A CDC class driver as well as a FAT FS has been developed, making it possible to have serial communication with a PC using a simple USB-OTG to USB cable. The USB interface can also be used for a memory stick for storage or field upgrade. In addition to these interfaces, the control boards have Board to Board connectors with Ethernet/SD-Card and 3.3V UART signals, so special functions can easily be developed for fast proof of concept without redesigning the whole board. The configuration of the signals is very flexible and can include UART, PWM and event outputs, GPIO as well as analog functions and Interrupt Inputs. The Add-On extension board is available with Bluetooth BLE module and SD-Card connector. SD- Card can be used for storage and/or field upgrade of the application software. The USB OTG Interface can be configured as CDC Class, HID class etc. and can be used to read an USB memory stick for field upgrade or storing Data. We offer Evaluation Kits (EVK) and add-on extension boards to start development today. By using the Evaluation Kit, you can literally design your GUI in a few hours since the kit contains all necessary parts needed for development. Power supply, programming adapter with USB cable, cables for I/O and power and a USB Stick with documentation and user examples for the on-board interfaces. The EVK enable you to quickly develop prototypes for the GUI utilizing the easy to use graphic TouchGFX® Designer, FreeRTOS and the built-in drivers for the on-board interfaces. You can directly connect sensors of your choice via the built-in I2C / SPI interfaces. The modules have one to two Board to Board connectors so add-on boards can easily be developed for functions like WiFi, LoRa, Ethernet and Sensors for verification without re-designing the whole board. Traditionally you would have to manage several suppliers with different mindsets for an HMI-project. Display and Touch system, Cover Lens with printing, Power Supply, Controller Board, eventual housing and cabling and on top of this, the assembly could be done in-house or by third parties with add on of transportation, stocking and test of sub-assemblies adding to cost and total energy consumption. EDTs SE solution takes away all the hazzle. Our unique value to the industry is within the touch and display and integration of the two core technologies. It's in our ability to use optical bonding to improve readability and mechanical robustness, to tune the touch sensor and interface to ensure precision, even with wet finger or while wearing gloves, and it's in our inhouse ability to integrate and ship the module with a standard or fully customized cover glass. In any case, to use this touch display, users need a proper MCU to power it and a graphical framework to take advantage of it. By using ST's MCU and software, we allow our innovations and expertise to shine brighter.
Smart Embedded roadmap EDT's Smart Embedded modules are already being used globally in:
Related articles: https://blog.st.com/smart-embedded-display/ https://www.electronicsweekly.com/news/embedded-world-video-interview-edts-smart-embedded-display- shortens-time-market-2020-02/
| Module size | 4.3" | 7.0" | 10.1" |
|---|---|---|---|
|
Notes: 1: Option for 12V only Power Supply input 2: Custom MCU options possible 3: Other Memory configurations possible 4: Pins are configurable for other functions |
|||
| Resolution | 480x272 | 800x400 | 1024x600 |
| Power Supply(1) | 7-36V | ||
| Brightness | 340nits | 300nits | 450nits |
| MCU(2) | STM32F746 | ||
| Internal FLASH | 1MByte | ||
| Internal SRAM | 340KByte | ||
| SDRAM(3) | 8MByte | 16MByte | |
| FLASH(3) | 16MByte | ||
| RS232 or 3.3V UART | √ | √ | √ |
| RS485 | √ | √ | √ |
| CAN | √ | √ | √ |
| SPI(4) | √ | √ | √ |
| I²C(4) | √ | √ | √ |
| USB OTG | √ | √ | √ |
| 3.3V GPIO(4) | √ | √ | √ |
Il controller è integrato con il display formando un modulo compatto. Include tutti i circuiti necessari al controllo del TFT, al backlight,
al touch capacitivo, nonchè il controllo di una serie di periferiche esterne (CAN, SPI, RS232/485, I²C, etc...). Il framework grafico
è basato su TouchGFX e FreeRTOS, librerie ed ambiente operativo che permettono soluzioni ad alta efficienza e bassi consumi.
EDT Smart Embedded® è la migliore scelta per il minor time-to-market possibile.
Il display montato sulla vostra apparecchiatura, sia esso un controllo industriale, uno strumento od un apparato medicale, è in definitiva l'immagine della vostra azienda. I display EDT sono realizzati per rispettare questa responsabilità ed offrire una perfetta esperienza utente. I TFT EDT hanno come obbiettivo il mondo industriale e sono perciò tarati su specifiche ottico-visive di alta qualità. Angolo visivo e range di temperatura estesi, lunga vita del backlight, elevato contrasto ed alta luminosità diventano così parametri naturalmente disponibili. Combinati con la proposta di touch panel capacitivi i moduli di EDT vi offrono l'opportunità di realizzare HMI allo stato dell'arte. Con la Soluzione Completa EDT le vostre applicazioni garantiranno la miglior esperienza utente ed aggiungeranno valore ai vostri prodotti.
Per facilitare l'apprendistato e la realizzazione del design delle GUI, EDT mette a disposizione degli Starter Kit per ogni size proposto. Ordina subito il tuo modello per iniziare la trasformazione delle HMI sulle tue applicazioni!
